Gigabyte B760M Aorus Elite GEN5 DDR5 LGA1700 Support for the 14th, 13th, and 12th Generation PCIe 5.0 mATX
Gigabyte B760M Aorus Elite GEN5 DDR5 LGA1700 Support for the 14th, 13th, and 12th Generation PCIe 5.0 mATX is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Shipped within 3 business days
Gigabyte B760M Aorus Elite GEN5 DDR5 LGA1700 Support for the 14th, ...
| Manufacturer | Gigabyte |
| Chipset | Intel B760 |
| Cpu socket | LGA 1700 |
| Form factor | mATX |
| Memory slots | 4 |
| Memory type | DDR5 |
Payment & Security
Cash on delivery - Instapay
Gigabyte B760M Aorus Elite GEN5 DDR5 LGA1700 Support for the 14th, 13th, and 12th Generation PCIe 5.0 mATX
Gigabyte B760M Aorus Elite GEN5 DDR5 — Performance Redefined
Step into the future of desktop computing with the Gigabyte B760M Aorus Elite GEN5 — engineered for gamers, PC builders, content creators, and professionals alike. Whether you're pushing high FPS in competitive games, editing 4K video, streaming, or crunching data, this mATX motherboard delivers the bandwidth, speed, and thermal resilience to power your ambition. With native DDR5 support, PCIe 5.0-ready expansion, and strong hybrid VRM design, this motherboard lets you unleash the full potential of 14th, 13th, and 12th Generation Intel CPUs.
Key Specifications
| Feature | Specification |
| CPU & Chipset | LGA 1700 socket — supports 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold & Celeron®; Intel® B760 Express chipset; 12+1+1 Twin Hybrid VRM phases with 60A DrMOS; 6‑layer PCB with 2× copper |
| Memory | 4× DDR5 DIMM slots, up to 256 GB (64 GB per slot); Dual‑channel; DDR5 speeds up to ~DDR5‑5600/5200/4800/4400 MT/s for high‑end CPUs; lower tiers also supported per CPU type; XMP support |
| Expansion Slots | 1× PCIe 5.0 ×16 (CPU), 1× PCIe 4.0 ×16 (chipset, runs at ×4) |
| Storage Interfaces | 2× M.2 sockets (both PCIe 4.0 ×4); 4× SATA 6 Gb/s ports; RAID support via chipset |
| Graphics Outputs | 1× HDMI 2.1 (4K@60Hz), 1× DisplayPort 1.2 (4K@60Hz), support depends on CPU’s integrated graphics |
| Networking & Connectivity | 2.5 GbE LAN (Realtek), Wi‑Fi 6E (AX210), Bluetooth 5.3; Rear USB‑C 20 Gbps; Front/USB header USB‑C 10 Gbps; other USB 3.2 Gen2 / Gen1 & USB2.0 ports |
| Audio | Realtek® High Definition Audio codec; supports 2/4/5.1/7.1‑channel output; S/PDIF external support |
| Form Factor & Power | Micro‑ATX; 8+4 solid‑pin CPU power connector; enhanced thermal armor; M.2 thermal guard; Smart Fan headers with hybrid design |
Why Choose This Product?
- Future‑ready PCIe 5.0 slot gives you the headroom for next‑generation graphics & storage.
- Top‑tier memory support (DDR5 + high frequency + XMP) makes big difference for content creation, multitasking, and gaming.
- Robust power delivery (12+1+1 VRM) and strong cooling = stable performance under heavy loads.
- Ultra‑fast networking: 2.5 GbE and Wi‑Fi 6E keep downloads, streaming and online gaming lag‑free.
- Rich I/O: high‑speed USB‑C ports, multiple M.2 slots, and modern display outputs for versatile workstation and gaming setups.
- Compact Micro‑ATX size gives flexibility in case selection without sacrificing core performance.
Ready to transform your build? Upgrade to the Gigabyte B760M Aorus Elite GEN5 today and unleash superior speed, connectivity, and power for your gaming, productivity, or creative rig. Elevate your PC—make every task, frame, and render count.
